AppStore API

Faction supports server-side extensions, similar in concept to BurpSuite extensions. An extension is a Java JAR that implements one or more Faction Extender interfaces, packaged with a small set of resource files, and uploaded through the Faction App Store UI. Faction invokes the extension when specific events fire — for example, an assessment being finalized, a report being generated, or a retest being completed.

Typical use cases: pushing vulnerabilities into an external tracker (Jira, ServiceNow), querying an external CMDB during assessment scheduling, or injecting custom HTML (charts, tables) into generated reports.

Available since Faction 1.2. Example project: https://github.com/factionsecurity/Faction-Jira-Extension

Extension Hooks

An extension class extends BaseExtension and implements one of the following interfaces.

The Operation enum lets a single hook differentiate between events — for example, only acting on Operation.Finalize inside AssessmentManager.

Project Layout

Extensions are built as Maven projects. Add the Faction Extender dependency to pom.xml:

<dependency>
    <groupId>com.factionsecurity</groupId>
    <artifactId>faction-extender</artifactId>
    <version>2.5</version>
</dependency>

Use maven-assembly-plugin with jar-with-dependencies so the JAR includes all transitive dependencies. The manifest must include Title, Version, Author, and URL entries — these are surfaced in the App Store UI.

Required resource files:

src/main/resources/META-INF/
├── resources/
│   ├── config.json        # User-configurable settings
│   ├── description.md     # Help text shown in App Store
│   └── logo.png           # Icon shown in App Store
└── services/
    └── com.faction.extender.<InterfaceName>   # Service descriptor

config.json

Defines the settings the user can edit in the App Store UI. Each entry produces an input field. Values defined here are defaults; users can overwrite them after install.

{
  "Jira Host":    { "type": "text",     "value": "https://yourhost.com" },
  "Jira API Key": { "type": "password", "value": "your api key" },
  "Jira Email":   { "type": "text",     "value": "[email protected]" }
}

type must be text or password. password fields are masked in the UI and are not returned to the UI after save.

description.md

Markdown describing what the extension does, why a user would install it, and how to configure it. Rendered in the App Store detail view.


PNG icon shown in the App Store listing.

services/ descriptor file

The filename must be the fully-qualified interface name your extension implements — one of:

• com.faction.extender.ApplicationInventory
• com.faction.extender.AssessmentManager
• com.faction.extender.ReportManager
• com.faction.extender.VerificationManager
• com.faction.extender.VulnerabilityManager

The file contents are the fully-qualified class name of your implementation, e.g. org.faction.JiraPlugin. Without this file, Faction cannot load the extension.

An extension that hooks multiple events includes one service descriptor file per interface implemented.

Minimal Example

A Jira extension that pushes vulnerabilities to Jira only when an assessment is finalized, and writes the returned issue IDs back to Faction as tracking IDs:

package org.faction;

public class JiraPlugin extends BaseExtension implements com.faction.extender.AssessmentManager {

    @Override
    public AssessmentManagerResult assessmentChange(Assessment assessment,
                                                    List<Vulnerability> vulns,
                                                    Operation opcode) {
        String project = "KAN"; // Jira project key

        if (opcode == Operation.Finalize) {
            for (Vulnerability vuln : vulns) {
                String issueId = sendVulnerabilityToJira(vuln, project);
                if (issueId != null) {
                    vuln.setTracking(issueId); // Sync Jira ID back to Faction
                }
            }
        }

        AssessmentManagerResult result = new AssessmentManagerResult();
        result.setAssessment(assessment);
        result.setVulnerabilities(vulns);
        return result; // Returning null would skip the Faction-side update
    }
}

Full reference implementation: https://github.com/factionsecurity/Faction-Jira-Extension

Build and Install

Build the JAR:

mvn clean compile assembly:single

This produces target/<artifact>-<version>-jar-with-dependencies.jar.

In Faction, go to Admin → App Store → Install Extension and upload the JAR. The extension installs in a disabled state. Click the extension in the list, fill in the settings defined by config.json, and enable it. The hook will fire on its registered events from that point on.

Reference

• App Store Extension API — hook interface reference.
• JIRA App Integration Example — full walkthrough.
• Faction-Jira-Extension — example project source.
• Faction-Vulnerability-Bar-Chart — example ReportManager extension that injects HTML bar charts into reports.

MCP Server

The Faction MCP server is a Model Context Protocol (MCP) server that exposes a Faction instance — assessments, vulnerabilities, retests, vulnerability templates, and audit logs — to any MCP-compatible AI client (Claude Code, Claude Desktop, OpenCode, GitHub Copilot CLI, LM Studio, and others).

It lets an AI agent read from and write to Faction directly, so workflows like running a CLI tool, parsing its output, creating a finding, and generating a report can be automated end-to-end without copying data between tools by hand.

Source repository: https://github.com/factionsecurity/faction-mcp (MIT licensed)

What you can do with it

• Drive Faction from an AI client: pull your assessment queue, open vulnerabilities, retests, and audit log entries.
• Create and update vulnerabilities programmatically, including from default templates.
• Generate or download assessment reports (PDF/DOCX) and have the client open them directly.
• Generate executive summaries from stripped-down vulnerability data optimized for LLM context windows.
• Wire CLI security tools (nmap, nuclei, custom scripts, etc.) into reproducible workflows by combining the MCP server with agent skill files.
• Use any AI provider, including local LLMs (LM Studio, Ollama-style runners), so assessment data does not have to leave your environment.

Requirements

• A running Faction instance.
• A Faction API key — generated from your user profile page in Faction.
• Docker, Docker Compose, Podman, or Podman Compose on the host that will run the MCP server.
• An MCP-compatible client (Claude Code, Claude Desktop, OpenCode, Copilot CLI, LM Studio, etc.).

Installation

There are two supported installation paths.

Option 1: Docker Desktop MCP Catalog

Install directly from the Docker Desktop MCP Catalog and enter FACTION_API_KEY and FACTION_BASE_URL when prompted. This is the lowest-friction option if you already use Docker Desktop.

Option 2: Docker Compose (Docker or Podman)

Works anywhere Docker Compose or Podman Compose is available.

1. Clone the repository and create the environment file

git clone https://github.com/factionsecurity/faction-mcp.git
cd faction-mcp
cp .env.example .env

2. Edit .env with your Faction details

FACTION_API_KEY=xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx
FACTION_BASE_URL=https://faction.yourcompany.com

To rotate credentials later, edit .env — no rebuild is required.

3. Build the image

docker compose build
# or
podman-compose build

4. Configure your MCP client

Add the server to your client’s MCP config. Use the absolute path to your cloned docker-compose.yml.

Claude Code / Claude Desktop (~/.claude/settings.json or claude_desktop_config.json):

{
  "mcpServers": {
    "faction": {
      "command": "docker",
      "args": [
        "compose",
        "-f", "/absolute/path/to/faction-mcp/docker-compose.yml",
        "run", "--rm", "-T", "faction-mcp"
      ]
    }
  }
}

OpenCode:

{
  "mcp": {
    "faction": {
      "type": "local",
      "command": [
        "docker", "compose",
        "-f", "/absolute/path/to/faction-mcp/docker-compose.yml",
        "run", "--rm", "-T", "faction-mcp"
      ],
      "enabled": true
    }
  }
}

Podman users substitute podman-compose for docker compose. The -T flag disables pseudo-TTY allocation so stdio passes cleanly between the client and the server.

After restarting the client, run its MCP listing command (/mcps in OpenCode, equivalent elsewhere) to confirm faction is connected.

Shared reports / images directory

The compose files mount one host directory into the container at /app/reports. By default this is /tmp. It is used for two things:

• Report downloads. get_assessment_report and generate_assessment_report write the PDF/DOCX here and return the host path so the client can open the file.
• Image uploads. upload_assessment_image reads from this directory. The agent is instructed to copy or save images into it first, then pass the host path. The server translates /tmp/foo.png → /app/reports/foo.png internally.

Routing image bytes through disk avoids round-tripping large base64 strings through tool arguments, where token-stream drift can corrupt the payload.

To use a different host folder, set FACTION_REPORTS_HOST_DIR to an absolute path in .env:

FACTION_REPORTS_HOST_DIR=/Users/me/faction-reports

Available Tools

The server exposes the following tool surface to the AI client.

Assessments

Vulnerabilities

Vulnerability Templates

Retests / Verifications

Audit Logs

Key Workflows

Creating a vulnerability

create_vulnerability, update_vulnerability, and add_templated_vulnerability accept severity, impact, and likelihood as risk-level names ("Critical", "High", "P1", etc.). The server resolves the name to the correct numeric ID for your Faction instance via get_risk_levels, so the LLM never needs to know the IDs and skills do not break when IDs differ between instances.

When required information is missing, create_vulnerability walks the user through an interactive workflow via MCP elicitation (supported by Claude Code, Claude Desktop, and other elicitation-capable clients):

1. Title and severity — if either is missing, the user is prompted. Risk levels are presented as a dropdown of the names actually configured on the instance.
2. Template offer — if no description, recommendation, or template ID is supplied, the server searches default templates by title and offers matches. Selecting one auto-populates description and recommendation.
3. Mirror severity — if severity is set but impact/likelihood are not, the server asks whether to mirror severity to both, or to set them explicitly.

If the client does not support elicitation, the tool returns an error listing the missing fields so the agent can ask the user in plain text.

Generating executive summaries

Use get_vulnerability_summary_data rather than get_assessment_vulnerabilities. It returns text-only, stripped vulnerability data optimized for LLM processing. After the AI drafts the summary HTML, it calls update_assessment to write it back to Faction.

Generating and downloading reports

Three tools cover report handling:

• generate_assessment_report — starts a fresh report build (use retest=true for finalized assessments) and polls up to max_wait_seconds (default 60).
• check_report_status — standalone poll when the initial wait expires. Pass last_known_gentime from the generate response.
• get_assessment_report — downloads the existing report. The file is written to the configured reports directory and the absolute host path is returned as file_path.

A typical run: ask the agent to generate a new report for an assessment ID; the server fires generation, waits, and reports completion; the agent then calls get_assessment_report and surfaces the file path.

Automating CLI Tools with Agent Skills

The MCP server gives the agent access to Faction. To turn ad-hoc agent runs into reproducible workflows, pair it with agent skill files (SKILL.md / AGENTS.md) that describe a fixed procedure: which command to run, how to parse the output, what severity to use, what fields to populate in Faction.

A typical skill for an nmap-driven information finding might:

1. Require explicit user authorization that the target is in scope.
2. Run a fast top-ports scan (nmap -Pn --top-ports 100 <target>).
3. Run a vulnerability scan against only the discovered open ports (nmap -sV --script=vuln -p <ports> <target>).
4. Parse the output into a list of ports, services, versions, and identified CVEs.
5. Call create_vulnerability with a fixed naming convention, the configured lowest severity tier (e.g. "Recommended"), and a markdown details field containing two tables (commands run, and ports/weaknesses).

Because the skill pins the procedure — command flags, severity, description structure, table format — the resulting findings are consistent across assessments and across whoever (or whatever agent) runs the skill. The same pattern applies to any CLI tool that produces parseable output.

A worked nmap skill example is published with the Faction blog post linked below.

Reference

• Repository and README: https://github.com/factionsecurity/faction-mcp
• Walkthrough with full nmap skill example: Automate Your Pentesting Workflow: Connecting Faction to AI Agents via MCP
• Faction core project: https://github.com/factionsecurity/faction
• Background on agent skills: https://agents.md/
